  • 10CM2 GSM Sample Cutter/Round Cutter for Fabric

    10CM2 GSM Sample Cutter/Round Cutter for Fabric

    10CM2 GSM Sample Cutter/Round Cutter for Fabric

    10CM2 GSM Sample Cutter/Round Cutter for Fabric

  • detailed description
  • Round Cutter / Sample Cutter



    Product information

    High-quality aluminum alloy material, the thickness of the feed can be steplessly adjustable (thickness adjustable range: 0-5mm), zui greatly extends the service life of the blade and rubber pad.


    Cutting area: 10 square centimeters (0.001 square meters)
    Cutting diameter: 35.7 mm
    Cutting depth: adjustable within 0-5 mm.


    The disc sampler cuts a circular sample of fixed area or diameter quickly and accurately. Its biggest advantage is: all aluminum alloy (handle, blade platen, outer casing) can be manufactured, the cutting depth of the blade can be adjusted according to the thickness of the sample to be cut...zui extended (thickening type) blade; and the use of the pad life. The materials to be cut include woven fabrics, non-woven fabrics, knitted fabrics and other textiles, especially for the actual samples given by customers (less than 15CM square meters). Carpet, plastic film, metal (aluminum, copper, tin, gold, nickel, etc.) film, styrofoam. Paper or wooden sheet. It is an indispensable instrument for textile and garment, fabric weaving, paper, cardboard carton, metal film, lithium polymer battery industry.



    Features

    Portable sampling knife, also known as (10 square centimeter (0.001 square meter) disc sampler), smaller in size, lighter in weight, easy to carry around, because the cutting area is ten times smaller than the traditional one. It can be more economical. A circular sample of 10 square centimeters (0.001 square meters) can be cut quickly, accurately and safely, and then weighed by the balance. Multiplied by 1000 is the weight per square meter of the sample. This instrument is suitable for cutting round samples of various textile garments, fabric weaving, paper industry, cardboard carton and metal film samples with thickness less than 5mm. Sampling area: 10cm2
