- Beaker Dyeing Machine
HTHP Beaker Dyeing Machine is ideally suitable for sample dyeing of fabric and yarn at high temperature and pressure.
Features of HTHP Beaker Dyeing Machine:
The machine comprises of tank, beaker and gear box
The beakers are capable of withstanding pressure upto 6.0 Kg/cm square.
Microprocessor based programmer is provided which ensures temperature control.
Promises long life and leak proof service even after many years of use.
Specifications of HTHP Beaker Dyeing Machine:
Electric Supply
: Single phase 220 Volts, AC Supply
Heater Supply
: 3000 watt Single Phase
Capacity of Beaker
: 250 ml Beaker X 12 Pcs.
Carriage Rotation
: At 22 rpm. (±2 rpm)
Maximum operating Temperature
: 135°C.
Maximum rate of heating
: 3.5°C/Min.
Control through Temperature Controller / Programmer based having auto/manual operation.
Heater rating
: 3 x 2 KW
Medium used for Heating
: Glycerine
Electrical Supply
: Single Phase A.C
Motor
: Reversible Synchronous Geared Motor
Overall dimensions of the Unit
: 700 ±05mm (L) x 470±05mm (H) x 370±05mm (W)
Net Weight of the Unit
: 35 Kg.
Net Weight of the Beaker (250ml)
: 10.980 Kg.
