     UV Aging Test Chamber Programmable Ozone Test Chamber

     UV Aging Test Chamber Programmable Ozone Test Chamber

     UV Aging Test Chamber Programmable Ozone Test Chamber

  • detailed description
  • Enviromental Test Chamer Programmable Ozone Aging Resistance Test Chamber


    Application

    Ozone Test chamber is used for testing rubber and polymer.

    Ozone aging test chamber is a major factor in rubber cracking although it is rare in the atmosphere, ozone aging tank simulates and enhance the condition of ozone in the atmosphere to study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging measures to enhance the life of rubber products

    Put the sample in certain density ozone environment, after having certain discoloration or the scheduled time and compare with the standard card.


    Applications of Ozone Test Chamber
    • Accelerated Aging Studies
    • Product Quality Control
    • Research & Development
    • Quality Assurance


    Standards

    OZ air series "ozone test chambers" are manufactured with flexibility for testing with following standards
    • ASTM D 518 IS-3400 (Part-20)
    • ASTM D 1149 ISO 1431-1 : 1989
    • ASTM D 1171
    • ASTM D 3395
    • ASTM D 4575
    • BIS, ISO, DIN, MIL
    Stainless chamber walls are sealed with high-grade fiber gasket to assure leak proof operation
    Ozone concentration 0~1000pphm
    Test chamber temperature RT~+70℃
    surface temperature fluctuations degrees + /-0.5 ℃

    Load 10 kg


    Technical parameter

     Model  Ozone Test Chamber Manufacturer
     Ozone concentration  0~1000pphm adjustable
     Relative humidity  60%RH above
     Temperature  RT+10~+70℃
     Ozone produced mode  Ozone generator or UV absorption method
      Inside air velocity  over 2 feet/sec

     Degree of ozone concentration

    fluctuation

     10%
     Inside size  500×500×600mm
     Air flow  A.0-6 cfm;B. 10-20 cfh
     Weight  250kg
     Power  AC220V,15A
     Accessories  tensile fixture 6 groups

    Equipment by the occurrence of silent and efficient ozone generator ozone gas, and a certain amount of air processed, the switch in the mixture into the chamber, the continuous line UV detector to detect the concentration of ozone, ozone generator control feedback to the systems to control system settings according to the occurrence of effective control of ozone to the ozone chamber to maintain the appropriate concentration of work by heating humidification systems to meet all the test conditions.



    Applicable industries

     It is widely used to control products quality in measuring quality control; Rubber & Plastics; automobile production; wire and cable; packing materials; instruments and meters; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research laboratories; inspection arbitration, and technical supervision departments and other rubber products.
